MIDI CC Channel change feature

As of firmware version 7.1.0, all the key and encoder product have channel change feature. Optimally, channel change with key would be better than encoder (detent encoder would be better than non detent encoder in this particular scenario)

How to set the keys to change channels

Enter WEB CONFIGURATOR

Pasted image 20231115205122.png

select HCI radio box and select MIDI channel - or +. That button will change the current channel + and -

Channel change limits

currently, it changes to up +3 and down to -3

LED INDICATOR

Some products support LED indicator so the user can check current channel offset. There're two LEDS. One left and one right.

  • LEFT LED STEADY: -3
  • LEFT LED FAST BLINK: -2
  • LEFT LED SLOW BLINK: -1
  • ALL LED OFF: 0
  • RIGHT LED SLOW BLINK: +1
  • RIGHT LED FAST BLINK: +2
  • RIGHT LED STEADY: +3
